The Raspberry Pi Camera Module 3 features a 12MP Sony IMX708 Quad Bayer sensor with Phase Detection Autofocus (PDAF) and HDR support. Delivering 1080p50 video and RAW10 output, it integrates seamlessly via CSI-2/libcamera systems, offering rapid focus control and enhanced low-light performance across standard, wide-angle, and NoIR variant configurations.
Specifications:
- Sensor: 12.0 Megapixel Sony IMX708 stacked CMOS (7.4 mm diagonal)
- Resolution: 4608 × 2592 pixels (1.4 µm × 1.4 µm pixel size)
- Focusing System: Phase Detection Autofocus (PDAF) with 2-wire serial actuator control
- Field of View (FOV): 75° diagonal (Standard / NoIR) or 120° diagonal (Wide variants)
- Video Modes: 1080p @ 50 fps, 720p @ 120 fps
- Dynamic Range Support: High Dynamic Range (HDR) mode (up to 3 MP output)
- Interface & Output: CSI-2 serial data output, RAW10 image format
- Physical Dimensions: 25 × 24 × 11.5 mm (12.4 mm height for Wide variants)
Use the form to request the item, and we will check the availability and get back to you through email when we have processed your request.
