The NVIDIA Jetson TX2 is an industrial-grade AI supercomputer-on-a-module designed for high-performance edge computing and autonomous machines. Powered by a 256-core NVIDIA Pascal GPU and a complex 64-bit ARM CPU complex, it delivers up to 1.33 TFLOPS of compute power within a 7.5 to 15-watt power envelope.
Specifications:
- Product Name: NVIDIA Jetson TX2 Module
- GPU: 256-Core NVIDIA Pascal Architecture GPU @ 1.3 GHz (1.33 TFLOPS FP16 performance)
- CPU: Dual-Core NVIDIA Denver 2 @ 2.0 GHz + Quad-Core ARM Cortex-A57 @ 2.0 GHz (64-bit)
- Memory (RAM): 8 GB 128-bit LPDDR4 (58.3 GB/s bandwidth)
- Onboard Storage: 32 GB eMMC 5.1 Flash Storage
- Video Encode & Decode: 4K @ 60 fps (H.264/H.265 encode), 4K @ 60 fps (H.264/H.265 decode)
- Camera Interfaces: Up to 6 cameras (12 lanes MIPI CSI-2, D-PHY 1.2)
- Networking: Gigabit Ethernet RJ45 Controller + Dual-Band 802.11ac Wi-Fi & Bluetooth 4.1
- PCIe & Expansion: PCIe Gen 2.0 (1x4 + 1x1 OR 2x1 + 1x2), USB 3.0, USB 2.0, UART, SPI, I2C, I2S, GPIO
- Display Output: HDMI 2.0 / DisplayPort 1.2 / eDP 1.4 / DSI (Supports up to 3 active displays)
- Power Consumption: Configurable dual power modes (7.5 W Max-Q or 15 W Max-P)
- Module Dimensions: 50 mm × 87 mm (400-pin board-to-board connector)
Use the form to request the item, and we will check the availability and get back to you through email when we have processed your request.
