The Winsen MQ-4 is a metal oxide semiconductor (MOS) gas sensor designed to detect methane ($CH_4$) and natural gas concentrations from 300 to 10,000 ppm. Utilizing a tin oxide ($SnO_2$) layer with an integrated heater, its conductivity increases with gas density, enabling fast-response leak detection with low cross-sensitivity to alcohol or smoke.
Specifications:
- Sensor Type: Semiconductor / Metal Oxide (SnO2)
- Target Gas: Methane (CH4), Natural Gas (LNG/CNG)
- Detection Range: 300 to 10,000 ppm
- Circuit / Loop Voltage (Vc): <= 24V DC (Typically 5V DC)
- Heater Voltage (Vh): 5.0V +/- 0.1V AC/DC
- Heater Power Consumption (Ph): <= 950 mW
- Heater Resistance (Rh): 26 Ohm +/- 3 Ohm (at room temp)
- Response / Preheat Time: <10 seconds response time; >48 hours preheat time for baseline stability
- Operating Temperature Range: -10°C to 50°C (Humidity <95% RH)
- Encapsulation / Housing: Bakelite base with SUS316 stainless steel anti-explosion mesh
