The Blue Robotics Vacuum Plug (Clear Anodized Aluminum) is a precision-engineered sealing mechanism for underwater watertight enclosures. Installed in a standard M10 bulkhead port, it allows users to pull a vacuum on an enclosure using a hand pump to test for water tightness before submersion, then seal it securely with an O-ring plug.
Specifications:
- Product Name: Blue Robotics Vacuum Plug
- Thread Specification: M10 x 1.5 Pitch Thread (Fits standard M10 bulkhead ports)
- Primary Function: Enclosure pressure/vacuum testing and quick venting/sealing
- Body Material: Clear Anodized 6061-T6 Aluminum
- Sealing Mechanism: Dual Nitrile/Buna-N O-Rings (Face seal and internal plug seal)
- Depth Rating: Up to 950 meters (95 bar / ~1375 psi hydrostatic pressure)
- Wrench Flat Size: 13 mm Hex
- Compatibility: Blue Robotics 2"", 3"", and 4"" Watertight Enclosures
- Included Components: Anodized M10 bulkhead body, vacuum plug insert, retaining clip, and O-rings
Use the form to request the item, and we will check the availability and get back to you through email when we have processed your request.
